RAMSES 811 top3

Item no.: 8119200

The RAMSES 811 top3 is a modern digital clock thermostat designed for time-dependent room temperature control in homes, apartments, and offices. Its flat design and flush-mounted installation make it discreet, while operation is possible directly on the device or via app using Bluetooth Low Energy (BLE), without the need for internet access.

It offers 3 programmable weekly schedules plus comfort, eco, and setback modes for energy-efficient heating management. Settings are configured easily through the app on a smartphone or tablet, providing intuitive and convenient control.

The thermostat includes an external input for connecting a room sensor, floor sensor, motion detector, or telephone contact, and features an intelligent control algorithm for accurate regulation. Powered by 2 AA batteries, it ensures flexible installation—even for retrofitting.

Compact, efficient, and user-friendly, the RAMSES 811 top3 is ideal for modern single-room or zone-based heating systems.


Find Stockist

RAMSES 811 top3

RAMSES 811 top3

Request further information now

Function description

  • Digital clock thermostat in flat design for time-dependent monitoring and control of room temperature
  • Operation on device or via app
  • Battery version (also for retrofitting with 2-wire connection)
  • Installation in flush-mounted socket
  • Direct Bluetooth Low Energy (BLE) connection between app and clock thermostat, no communication via the Internet
  • Settings configured conveniently via the app with intuitive operation from a smartphone or tablet
  • Increased user convenience
  • 3 individually programmable weekly programs, as well as comfort, eco and setback function
    Suitable for energy-saving room temperature regulation in houses, apartments, etc.
  • Illuminated display through keystroke
  • External input for the flexible connection of the external room temperature sensor, floor sensor, motion detector or telephone contact
  • Intelligent control algorithm (pulse-duration controller, hysteresis controller)
  • Suitable for on/off heating systems, zonebased or single-room control, electric heating units

Technical data

Specification Details
Operating voltage 2 AA batteries
Type of contact NO contact
Switching capacity 10 A at 250 V AC, cos φ = 1, at 250 V AC, cos φ = 0.6
Switching capacity min. 1 mA
Setting range temperature 2°C … 30°C
Setting range frost protection 2°C … 10°C
Time basis Quartz
Program Weekly program, Daily program, Holiday program, 3 basic programs
Number of memory locations 42
External inputs 1
Control types Pulse width modulation, Hysteresis controller
Control period 5 – 30 min
Control capture range ±0.2 – ±5 K
Control accuracy ≤ ± 0.2 K
Mode of operation Type 1 B as per EN 60730-1
Control types 2-point
Switching output Potential-free, not for SELV
Suitable for SELV Yes
Switching hysteresis ±0.2 – ±1 K
Time accuracy at 25 °C ≤ ± 1 s/day (quartz)
Power reserve Max. 10 mins without losing time
Battery life Approx. 1 year, depending on switching frequency
Installation type Flush-mounted wall installation
Type of protection IP 40
Protection class II according to EN 60 730-1
