Function description

  • Universal dimmer for R, L and C loads with automatic load detection
  • Operation by button or app via Bluetooth Low Energy
  • Adjustable minimum brightness for LEDs
  • Adjustable dimming response
  • Adjustable staircase light function
  • App for Android and iOS
  • Time functions
  • Astronomical functions
  • Night break
  • Optimised settings for LEDs, incandescent lamps
  • Easy installation thanks to a highly compact housing
  • Ideal for all dimmable LEDs and halogen lamps
  • Memory function saves the most recently set light level value and then dims to this value the next time it is switched on
  • Convenient snooze function
  • Special load setting
  • Sequential scenes
  • Password protection possible
  • „Gentle“ lamp-conserving function for switching on and off
  • Automatic detection of the load type
  • Overheating protection against overload
  • Short-circuit protection

Technical data

Parameter Specification
Operating voltage 230 V AC
Frequency 50 – 60 Hz
Installation type Flush-mounted
Stand-by consumption ~0.15 W
LED lamp < 2 W 250 W
LED lamp 2–8 W 250 W
LED lamp > 8 W 250 W
Incandescent/halogen lamp load 250 W
Transformer electronic (C) 250 W
Programmierung per App
Multi-function
Setting App
Load detection
Ambient temperature -25°C to 45°C

Downloads

Tender text PDF theRonda P360 DALI-2 S UP WH (91,1 kB)
Hand book PDF theRonda P360 DALI-2 S UP WH (91,1 kB)
Operating instructions PDF theRonda P360 DALI-2 S UP WH (91,1 kB)
